Germanjet 16 Series
16 series is design for hydraulic cyclinder with limited head space or clevis rod ends hydraulic cyclinder. Sensing rod is made by stainless steel which installed inside the hydraulic cyclinder. It has a wide variety of signal output selection included analog voltage, current, and SSI. It is a perfect combination with hydraulic valve to form a close-loop servo hydraulic system.
It adopts the non-contact magnetostrictive to provide feedback of fluid level and multi-interface level of a storage tank or process vessel. The non-contact feature provides exceptional ease of installation and guaratees almost unlimited mechanical life expectancy. The high versatile IP67 profile housing offers full protection against outside agents for use in harsh environments with high contamination and presence of dust.
Model Number |
Output |
PDF |
160 |
Voltage Output |
 |
161 |
Current Output |
|
162 |
SSI |
|
